SPECIFICATIONS

Wire Resolution

Typical AW G 38

Penetration resolution

Typical AW G 34

Spatial resolution

Vertical:1.3mm, horizontal:1.3mm

Penetration

Typical 6mm

Resolution of organic matter

/

Grayscale and mixture resolution

1-40mm

Resolution of inorganic objects

/

Effective material resolution

/

X-Ray dosage each inspection

≤3.0μSv (uGy)

Boundary Leakage

≤2.0μSv /h(uGy/h)

Power consumption

0.5K W

Safety performance requirements

Meet the requirements of G B 15208.1-2005

Electrical safety

Meet the requirements of G B 15208.1-2005

Environmental applicability

Meet the requirements of G B 15208.1-2005

Leakage current

≤5.0mA

Film Safety

Guarantee A S A / I S O 1600 Film

Weight

250kg

Atmospheric pressure

86kPa-106kPa A C

Operation Power

220V(±10%-15%) 50±3Hz

Operation system

L I N U X
